Miniature door loops
M 13 40
The miniature door loop M 13 40 for alarm glass is mounted concealed in the window rebate. To unhook the sash, only one locking screw on the door loop needs to be loosened.
Downloads
Attributes
| Aperture angle | 180° |
|---|---|
| Applications | Window rebate |
| Approvals | G 108094, VdS-class C |
| Cable length socket / plug | See “product versions” |
| Connector alarm glass cable link | 4-pole |
| Connector door loop | 6-pole |
| Current consumption | 0.5 A (0.14 mm²), continuous and inrush current |
| Material spring | Stainless steel |
| Operating voltage | 48 V DC |
| Protection category | IP 67 |
| Special features | Free of lead, cadmium, CFC and halogen, small size |
| Spring length | 200 mm |
| Temperature range | Free of lead, cadmium, CFC and halogen |
Packaging
| Delivery contents | Door loop, mounting instruction, fixing material |
|---|
